Model: RS460105
The RS460105 LC Duplex MM Fiber Optic Adapter is designed for precise alignment of multimode LC connectors in high-speed short-distance networks. Featuring a duplex configuration, it allows simultaneous transmission and reception on two multimode fibers.
With a durable beige polycarbonate housing and zirconia ceramic alignment sleeve, this adapter provides reliable connections with minimal insertion loss. It is ideal for use in OM2, OM3, and OM4 networks, commonly found in data centers, LAN backbones, and enterprise telecom infrastructures.
| Specification | Value |
|---|---|
| Model | RS460105 |
| Connector Type | LC Duplex |
| Fiber Mode | Multimode (MM) |
| Supported Standards | OM2 / OM3 / OM4 |
| Polish Type | UPC |
| Insertion Loss | ≤ 0.2 dB |
| Durability | > 500 mating cycles |
| Operating Temperature | -40°C to +85°C |
| Sleeve Material | Zirconia Ceramic |
| Housing Material | Polycarbonate (Beige) |
| Applications | Data centers, patch panels, enterprise LANs, telecom |
| Fiber cable connector | LC/UPC |
|---|---|
| Fiber count | 2 |
| Fiber mode | Multi Mode |
